Processor |
Processor family |
Intel® Core™ i5 |
Processor manufacturer |
Intel |
Processor model |
i5-10500 |
Processor frequency |
3.1 GHz |
Processor generation |
10th gen Intel® Core™ i5 |
Processor cores |
6 |
Processor boost frequency |
4.5 GHz |
Processor socket |
LGA 1200 (Socket H5) |
Processor cache |
12 MB |
Processor cache type |
Smart Cache |
Processor threads |
12 |
System bus rate |
8 GT/s |
Processor lithography |
14 nm |
Processor operating modes |
64-bit |
Processor codename |
Comet Lake |
Thermal Design Power (TDP) |
65 W |
Tjunction |
100 ┬░C |
PCI Express slots version |
3.0 |
Maximum number of PCI Express lanes |
16 |
PCI Express configurations |
1x16, 2x8, 1x8+2x4 |
Maximum internal memory supported by processor |
128 GB |
Memory types supported by processor |
DDR4-SDRAM |
Memory clock speeds supported by processor |
2666 MHz |
Memory bandwidth supported by processor (max) |
41.6 GB/s |
Memory |
Internal memory |
16 GB |
Maximum internal memory |
128 GB |
Internal memory type |
DDR4-SDRAM |
Memory layout (slots x size) |
1 x 16 GB |
Memory slots |
4x DIMM |
Ports & interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
HDMI ports quantity |
1 |
DVI port |
N |
DisplayPorts quantity |
2 |
Ethernet LAN (RJ-45) ports |
1 |
Microphone in |
Y |
Headphone outputs |
1 |
Line-out |
Y |
Combo headphone/mic port |
Y |
Power |
Power supply |
260 W |
Operational conditions |
Operating temperature (T-T) |
5 - 35 ┬░C |
Storage temperature (T-T) |
-40 - 60 ┬░C |
Operating relative humidity (H-H) |
20 - 80% |
Storage relative humidity (H-H) |
20 - 90% |
Operating altitude |
-15.2 - 3048 m |
Non-operating altitude |
-15.2 - 10668 m |
Weight & dimensions |
Width |
145 mm |
Depth |
296 mm |
Height |
346 mm |
Weight |
4.8 kg |
Network |
Ethernet LAN |
Y |
Wi-Fi |
N |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Cabling technology |
10/100/1000Base-T(X) |
Software |
Operating system installed |
Windows 10 Pro |
Operating system architecture |
64-bit |
Storage |
Total storage capacity |
512 GB |
Optical drive type |
DVD┬▒RW |
Storage media |
SSD |
Card reader integrated |
N |
Number of storage drives installed |
1 |
Total SSDs capacity |
512 GB |
Number of SSDs installed |
1 |
SSD capacity |
512 GB |
Graphics |
Discrete graphics card |
N |
On-board graphics card |
Y |
Discrete graphics card model |
Not available |
On-board graphics card model |
Intel® UHD Graphics 630 |
On-board graphics card base frequency |
350 MHz |
On-board graphics card dynamic frequency (max) |
1150 MHz |
Maximum on-board graphics card memory |
64 GB |
Number of displays supported (on-board graphics) |
3 |
On-board graphics card DirectX version |
12.0 |
On-board graphics card OpenGL version |
4.5 |
On-board graphics card ID |
0x9BC8 |
Packaging content |
Display included |
N |
Processor special features |
Intel 64 |
Y |
Enhanced Intel SpeedStep Technology |
Y |
Embedded options available |
N |
Intel® InTru™ 3D Technology |
Y |
Intel® Clear Video HD Technology (Intel® CVT HD) |
Y |
Intel Clear Video Technology |
Y |
Intel VT-x with Extended Page Tables (EPT) |
Y |
Idle States |
Y |
Thermal Monitoring Technologies |
Y |
Intel Stable Image Platform Program (SIPP) |
Y |
Intel® AES New Instructions (Intel® AES-NI) |
Y |
Intel® Secure Key |
Y |
Intel® OS Guard |
Y |
Intel Trusted Execution Technology |
Y |
Execute Disable Bit |
Y |
Intel Software Guard Extensions (Intel SGX) |
Y |
Processor package size |
37.5 x 37.5 mm |
Supported instruction sets |
SSE4.1, SSE4.2, AVX 2.0 |
Scalability |
1S |
CPU configuration (max) |
1 |
Thermal solution specification |
PCG 2015C |
Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
Intel Virtualization Technology (VT-x) |
Y |
Processor ARK ID |
199277 |
Intel® Turbo Boost Technology |
2.0 |
Intel® Hyper Threading Technology (Intel® HT Technology) |
Y |
Intel® Quick Sync Video Technology |
Y |
Intel® Identity Protection Technology (Intel® IPT) |
Y |
Design |
Chassis type |
Tower |
Product colour |
Black |
Volume |
13.6 L |
Placement supported |
Vertical |
Cable lock slot |
Y |
Cable lock slot type |
Kensington |
Performance |
Product type |
PC |
Market positioning |
Business |
Motherboard chipset |
Intel Q470 |
Audio chip |
Realtek ALC623-CG |
Audio system |
High Definition Audio |
Built-in speaker(s) |
Y |
Number of speakers |
1 |
Password protection |
Y |
Password protection type |
HDD, Power on, Supervisor |
Sustainability |
Sustainability certificates |
RoHS, ENERGY STAR |
